MC15 MULTI COMPONENT LOAD CELL称重传感器

2024-12-31 0

Various capacity of detecting up to components.
Minimize interaction between components.

2-Component loadcells

MODEL		Rated Capacity
MODEL		Fx	Fy	Fz	Mx	My	Mz
MC15-2A	10	10	10	(30)	(2)	(2)	(2)
	20	20	20	(50)	(5)	(5)	(5)
	50	50	50	.(100)	(10)	(10)	(10)
	100	100	100	.(200)	(20)	(20)	(20)
	200	200	200	.(500)	(50)	(50)	(50)
	500	500	500	.(750)	(100)	(100)	(100)
MC15-2B	10	10	(30)	10	(2)	(2)	(2)
	20	20	(50)	20	(5)	(5)	(5)
	50	50	.(100)	50	(10)	(10)	(10)
	100	100	.(200)	100	(20)	(20)	(20)
	200	200	.(500)	200	(50)	(50)	(50)
	500	500	.(750)	500	(100)	(100)	(100)

3-Component loadcells

MODEL		Rated Capacity
MODEL		Fx	Fy	Fz	Mx	My	Mz
MC15-3A	10	10	10	10	(2)	(2)	(2)
	20	20	20	20	(5)	(5)	(5)
	50	50	50	50	(10)	(10)	(10)
	100	100	100	100	(20)	(20)	(20)
	200	200	200	200	(50)	(50)	(50)
	500	500	500	500	(100)	(100)	(100)
MC15-3B	10	10	10	(2)	(2)	(2)	1
	20	20	20	(5)	(5)	(5)	2
	50	50	50	(10)	(10)	(10)	5
	100	100	100	(20)	(20)	(20)	10
	200	200	200	(50)	(50)	(50)	20
	500	500	500	(100)	(100)	(100)	50
MC15-3C	10	10	(30)	10	(2)	1	(2)
	20	20	(50)	20	(5)	2	(5)
	50	50	.(100)	50	(10)	5	(10)
	100	100	.(200)	100	(20)	10	(20)
	200	200	.(500)	200	(50)	20	(50)
	500	500	.(750)	500	(100)	50	(100)

SPECIFICATIONS

Specifications		Accuracy
Rate	capacity (R.C)	10kgf(98.07N) Fx, Fy, Mz
	output (R.O)	1.0mv/v
Nonlinearity		0.5% of R.O.
Hysteresis		0.5% of R.O.
Repeatability		0.3% of R.O.
Temperature effect	on rated output	±0.03% R.O./℃
	on zero balance	±0.03%/℃
Terminal resistance		350 ±3.5Ω
Insulation resistance bridge		2000MΩ
Excitation recommended		10V
Safe overload		120% R.C
Cable length		Φ3, 4core shield cable, 3m
Degree of interference		3% R.O.
